TT&C Command Receiver
Telemetry, Tracking and Command Units
KONGSBERG delivers advanced command receivers, telemetry transmitters, and transceiver units designed for both SmallGeo and GEO telecommunications satellites. Each product features built in frequency flexibility, enabling wideband in orbit selection of uplink and downlink frequencies across L-, S-, C-, X-, Ku-, K+, Ka-, and Q bands.
Systems can be configured for single, dual, or fully agile frequency operation, offering a wide in orbit tuning range of up to 2 GHz bandwidth on the transmit side. With late stage, flexible on ground frequency setting, programs gain adaptability without impacting schedules. Leveraging standard, on stock crystal oscillator frequencies, KONGSBERG reduces lead time while maintaining full ESA and multi prime environmental qualification.
Supporting a 28 V to 100 V bus range and already accepted by major satellite operators and primes, these units deliver unmatched versatility, reliability, and readiness for modern telecom missions.
Highlights
- CAN-Bus or Platform Specific Interface
- In-Orbit Switchable FM/PM Mode
- In-Orbit Selectable datarate
- Excellent Interferer Immunity
Heritage
More than 200 TT&C units contracted.
Key features
- S-, C-, X-, Ku-, K+, Ka-band
- Input Level Range: -50 to -112 dBm
- Data: 250, 500, 1000, 2000 or 4000 bps on 8 kHz / 16 kHz subcarrier
- High Datarate: 4000, 8000, 16000, 32000 bps
- 4 kHz to 100 kHz range tones
- BER < 10-6 at telecommand threshold level (1000 bps)
