DPS i4

Position sensor

With the DPS i-series, KONGSBERG fuses decades of experience within GNSS and inertial technology in order to create a fully scalable and future-proof reference solution with emphasis on operational efficiency for DP applications.

Awards

  • Annual Offshore Support Journal

    Annual Offshore Support Journal

    Dynamic Postioning Award 2018

  • Dredging and Port Construction

    Dredging and Port Construction

    Innovative Dredging Technology of the Year 2018

Sensors Teaming Up for Increased Operational Efficiency

An unmatched integration of the latest within multi GNSS and KONGSBERG’s unique motion gyro compass (MGC™) facilitate the possibility to operate with no additional augmentation services without compromising on DP performance. The DPS i-series is still fully prepared to utilize differential corrections and SBAS services when required. DPS i4 utilizes data from all available GNSS constellations including GPS, GLONASS, Galileo and BeiDou.

Designed for Robust Performance

The integration ensures a continuous position solution by bridging gaps in the GNSS reception and increasing position stability in periods with limited GNSS availability due to masking, scintillation and interference. GNSS and INS are perfectly matched as they overcome each others limitations. Using both systems is superior to using either system alone. RAIM (Receiver Autonomous Integrity Monitoring) extended by data from the INS provides ultimate reliability of the position and velocity data under difficult GNSS conditions.

Multi-Use of Sensor and Active Decision Support

By using the MGC as the inertial sensor, a high-quality WheelMark gyro compass becomes a part of the solution. In addition, MGC can serve other on-board systems such as navigation equipment and other systems that require attitude data. The DPS i-series has an intuitive and easy-to-use graphical user interface developed in close co-operation with experienced DP operators. The HMI (Human-Machine Interface) enables the operators to assess the quality of their positioning quickly and effectively during operation.

Key features

  • Multi-frequency GPS, GLONASS, BeiDou, Galileo, and SBAS receiver GNSS antenna
  • Highly optimized integration of INS and GNSS without the use of 3rd party DGNSS services
  • Dual frequency ionospheric compensation
  • INS aided RAIM capability for enhanced integrity and reliability
  • Fully capable to utilize differential correction services if required
  • High-precision lever arm compensation of position and velocity
  • GNSS heading (requires two GPS systems)
  • Spoofing detection capabilities
  • Automatic data recording with replay functionality
  • Remote service and diagnostics by utilizing K-IMS
  • Galileo High Accuracy Service (HAS) ready
  • GPS L5 ready

Product range

    Downloads

    Data sheet
