K-Bridge ECDIS display
The K-Bridge Electronic Chart Display and Information System - ECDIS system, is a fully compliant and easy to operate ECDIS for new builds and retrofit installations
- Radar video overlay from K-Bridge ARPA radar
- Autopilot control with simplified "curved EBL"
- "Active lights" display for simplified visual position confirmation
- Docking function provides prediction of ship movement
- Full route planning and validation functions
- Continuous monitoring of own ship in relation to route plan and waters
- Displays up to 100 Automatic Radar Plotting Aid (ARPA) tracked targets
- Displays targets and information from AIS - Automatic Identification System
- EBL / VRM gives the correct range and bearing from own ship
- Remote control of K-Bridge autopilot providing track-keeping functions
- Echo sounder monitoring and recording of chart depth information
- Voyage recording and replay
- Navtex interface
- IMO defined functions
- Type approved
The ECDIS system uses official vector charts and accepts CM-93 vector charts from C-Map, and is compatible with ARCS from The United Kingdom Hydrographic Office. This means a world-wide coverage of electronic charts. K-Bridge is a fully compliant and easy to operate ECDIS system for new builds and retrofit installations.
ECDIS chart formats
- C-Map CM 93 edition 2
- C-Map CM 93 edition 3
- C-Map ENC
- S-57 edition 3
- S-63 including Primar and IC-ENC (encrypted S-57 charts)
- DNC (Digital Nautical Charts) available as an option
- Slave displays with dedicated operator panel
- 26" TFT display: 1920 x 1200 pixels - console mounted or drop in kit
The equipment is designed to conform to the following standards:
- IEC 61174 Ed.2.0 ECDIS Operational and Performance Requirements. Method of Testing and Required Test Results
- IMO Resolution A.817 (19), Performance Standard for Electronic Chart Display and Information Systems
- IEC 60945 Ed.3.0 Marine Navigational equipment, General Requirements. Methods of Testing and Required Test Results
- NMEA 0183 version 2.30 Standard for interfacing Marine Electronic Devices
- IEC 61162 Ed.2.0 Maritime navigation and radio communication equipment and systems - Digital interfaces
- IEC 529 Second edition (1989-11), Degrees of protection provided by enclosures (IP code)
- AIS interface is compatible with ITU-R M.1371 and IEC 61993-2
- Input voltage: 115/230 VAC +/- 10%
- Frequency: 50/60 Hz +/- 5%
- Power consumption: 340 W
The K-Bridge ECDIS is in compliance with IEC 60945.
